CAPACITY:........................... 500 TONS
SIZE OF I-BEAMS:.................... 27" HIGH X 10" WIDE
DISTANCE BETWEEN STRAIGHTENERS:..... 22-1/2"
RAM-PAC PUSH CYLINDERS:
CYLINDER CAPACITY:.............. 250 TONS EACH
CYLINDER OUTSIDE DIAMETER:...... 8"
CYLINDER ROD DIAMETER:.......... 4"
CYLINDER STROKE:................ 13"
RAM-PAC HYDRAULIC UNIT:
SERIAL #:....................... 4-23-99
MODEL:.......................... HEP-560-4-5
SERIES:......................... 500
PSI MAX:........................ 10,000
PENDANT CONTROL
110V
LEROY SOMER CLAMPING CYLINDERS:
CYLINDER OUTSIDE DIAMETER:...... 3.5"
CYLINDER ROD DIAMETER:.......... 1.5"
CYLINDER STROKE:................ 14”
PRINCE HYDRAULIC UNIT:
2000 PSI
1.5 HP, 460V
| Specifications | ||
|---|---|---|
| Tonnage | 500 tons | |
| Dimensions | 23-1/2"L X 9'W X 4' H | |
Brand
Not Specified
Type
Beam Cambering Machines
Stock No.
10174
 |
419-269-2000 |
Stock #: 10174
CAPACITY:........................... 500 TONS
SIZE OF I-BEAMS:.................... 27" HIGH X 10" WIDE
DISTANCE BETWEEN STRAIGHTENERS:..... 22-1/2"
RAM-PAC PUSH CYLINDERS:
CYLINDER CAPACITY:.............. 250 TONS EACH
CYLINDER OUTSIDE DIAMETER:...... 8"
CYLINDER ROD DIAMETER:.......... 4"
CYLINDER STROKE:................ 13"
RAM-PAC HYDRAULIC UNIT:
SERIAL #:....................... 4-23-99
MODEL:.......................... HEP-560-4-5
SERIES:......................... 500
PSI MAX:........................ 10,000
PENDANT CONTROL
110V
LEROY SOMER CLAMPING CYLINDERS:
CYLINDER OUTSIDE DIAMETER:...... 3.5"
CYLINDER ROD DIAMETER:.......... 1.5"
CYLINDER STROKE:................ 14”
PRINCE HYDRAULIC UNIT:
2000 PSI
1.5 HP, 460V
