| Specifications | ||
|---|---|---|
| Dimensions | 138" X 65" X 72" | |
| Weight | 11800 pounds | |
Brand
WARNER & SWASEY
Type
Lathes, Turret
Stock No.
18372
 |
419-269-2000 |
Stock #: 18372
SERIAL .................. 2207689
LOT ..................... 72
Model ................... M-3470/2A TurretChuck ................... 16" 3-jaw
Swing Over Bed Ways ..... 20-1/2"Swing Over Cross Slide .. 16"Center Distance ......... 43"Spindle Hole ............ 3-3/4"Spindle Nose ............. A - 11Spindle Speeds ........... 16 To 1117 Rpm'sFeeds Cross .............. .0025 To .082 I.P.R.Feeds Long ............... .005 To .167 I.P.R.Coolant .................. YesTool Post ................ 4 Way On Front CarriagesRapid Traverse ........... Front & Rear CarriagesRear Turret .............. FixedMotor .................... 15/30 HP
