Brand
SAF
Type
Rolling Mills
Stock No.
22814
 |
419-269-2000 |
Stock #: 22814
The DS60HV PLUS is a hydraulic roll bender with three gear driven shafts. This roll bending machine can be ordered with a mechanical top roll positioner, or can be purchased with a hydraulic cylinder and mechanical stop, for the top roll position and for repeatability. This can also include an LED display indicator. This machine is very capable for achieving what you need, at a consistent and great quality.DS60HV PLUS TECHNICAL DATA:• Driven Rolls - 3• Hydraulic Roll Adjustment• Shaft Diameter - 50mm• Standard Shaft Working Length - 4.50"• Universal Tool Set - 1 Set• Motor - 5.5 HP• Shaft Revolutions Per Minute - 8-16 (2 Speed)• Machine Dimensions - 27" x 53" x 59"h• Machine Weight - 1,250 lbs.This machine can bend profiles of all types:• Round Tubes• Pipes• Square Tubes• Angle• Various Channels• Extrusions
