SERIAL ....................... 178953
CATALOG NO. .................. 8117C
SWING OF LATHE ............... 16-1/4"
| Specifications | ||
|---|---|---|
| Weight | 2075 pounds | |
Brand
SOUTH BEND
Type
Lathes, Engine
Stock No.
13601
 |
419-269-2000 |
Stock #: 13601
SERIAL ....................... 178953
CATALOG NO. .................. 8117C
SWING OF LATHE ............... 16-1/4"SWING OVER CROSS SLIDE ....... 9-5/8"DISTANCE BETWEEN CENTERS ..... 33"SPINDLE SPEEDS (BELT DRIVE) .. (8) 30 TO 980 RPMFEEDS ........................ (48) .0015 TO .0841 IPRTHREADS ...................... (48) 4 TO 224 TPIHOLE THRU SPINDLE ............ 1-3/8"
STEADY REST .................. 5"TAPER ATTACHMENT ............. YES
TAIL STOCK ................... YESTHREAD DIAL .................. YESMICROMETER CARRIAGE STOP ..... YESCHIP PAN ..................... YES
CHUCK ........................ 3 JAWSPINDLE CONTROLS.............. FORWARD/REVERSEMAIN MOTOR ................... 1-1/2 HORSEPOWER
