| Specifications | ||
|---|---|---|
| Weight | 5525 pounds | |
Brand
ROCKFORD
Type
Shapers
Stock No.
15730
 |
419-269-2000 |
Stock #: 15730
SERIAL ................................. 93 HB 83MAXIMUM LENGTH OF STROKE ............... 22"HORIZONTAL TRAVEL OF TABLE ............. 20"VERTICAL TRAVEL OF TABLE ............... 10.5"DISTANCE PLAIN TABLE TO RAM ............ 4" MIN, 15" MAXDISTANCE UNIVERSAL TABLE TO RAM ........ 3-1/8" MIN, 14-1/8" MAXVERTICAL HEAD ADJUSTMENT ............... 7"POWER DOWN FEED RANGE (VARIABLE) ....... .000" TO .018"TABLE FEEDS ............................ .000" TO .100"CUTTING SPEED RANGE .................... 10 TO 140 FPMRAPID TRAVERSE ......................... YESAREA OF TABLE .......................... 13" X 20"MOTOR, HORSEPOWER ...................... 7-1/2
