SERIAL ............................... D-25-1
MODEL ................................ HDB-30
CAPACITY ............................. 15 TON
5 POSITION HORIZONTAL TOOL TRANSFER... YES
MAX PIPE WORKING DIAMETER ............ 38.1MM
ACTION SPEED AT NORMAL OPERATION...... 3-4 SEC/1PUNCH
ACTION SPEED AT NORMAL OPERATION...... 5-6 SEC/2PUNCH
CLAMPING STROKE ...................... 45MM
MAX CLAMPING THRUST .................. 11,000 KG
F-STOPPER STROKE ..................... 45MM
MAX STROKE OF PUNCHING ............... 70MM
MAX THRUST OF PUNCHING ............... 13,600 KG/15 TON
PUNCH INDEX STROKE ................... 60MM
| Specifications | ||
|---|---|---|
| Weight | 4275 pounds | |
Brand
IMS
Type
Tube End Forming Machinery
Stock No.
14540
 |
419-269-2000 |
Stock #: 14540
SERIAL ............................... D-25-1
MODEL ................................ HDB-30
CAPACITY ............................. 15 TON
5 POSITION HORIZONTAL TOOL TRANSFER... YES
MAX PIPE WORKING DIAMETER ............ 38.1MM
ACTION SPEED AT NORMAL OPERATION...... 3-4 SEC/1PUNCH
ACTION SPEED AT NORMAL OPERATION...... 5-6 SEC/2PUNCH
CLAMPING STROKE ...................... 45MM
MAX CLAMPING THRUST .................. 11,000 KG
F-STOPPER STROKE ..................... 45MM
MAX STROKE OF PUNCHING ............... 70MM
MAX THRUST OF PUNCHING ............... 13,600 KG/15 TON
PUNCH INDEX STROKE ................... 60MM
