| Specifications | ||
|---|---|---|
| Dimensions | 7'L X 22'W X 8'H | |
Brand
FINNSONIC
Type
Washers
Stock No.
15591
 |
419-269-2000 |
Stock #: 15591
SERIAL ......................... 5130091-8-14
MODEL .......................... V031A
YEAR ........................... 2014
6 STAGE SYSTEM:
STAGE 1 ........................ UTLRASONIC CLEANING
STAGE 2 ........................ STORAGE TANK W/ OIL SEPERATION
STAGE 3 ........................ JET TURBULATION RINSING
STAGE 4 ........................ TANK RINSING
STAGE 5 ........................ HOT AIR BLOW DRY
STAGE 6 ........................ VACUUM DRY WITH INFRA RED HEATING
ULTRASONIC WASH TANKS CODE ..... V031VG50EXTERNAL DIMENSIONS ............ 19"x30"x36"H / 22"X35"X36"H
LOAD CAPACITY .................. 169 LBS
TANK DIMENSIONS ................ 14" x 20" x 13"FILLING VOLUME ................. 11 GALLONS
DISPLACEMENT RESERVE ........... 2 GALLONS
MATERIALS TANK ................ AISI 304 / AISI 316L / SS2378HEATING POWER (W) .............. 2000TEMPERATURE RANGE .............. (C) AAMBIEN -80 DEGREES CELSIUSULTRASONIC TECHNOLOGY .......... FINNSONIC GENIUSULTRASONIC FREQUENCY (KHZ) ..... 30 (40 for V031VG50H)
ULTRASONIC POWER NOM/PEAK ...... (W) 600/1200BOOSTER ........................ YES
SWEEP .......................... YES
DEGAS .......................... YES
FILLING VALVE .................. R 1/2"
DRAIN VALVE .................... R 1"
LEVELS SENSOR .................. FLOOR TYPE
VOLTAGE (VAC) .................. 380V/220V/240V /50-60HZ
CONNECTED LOAD ................. (W) 4000
FUSES .......................... 3X10A
NOTES:
NON AGGRESSIVE AQUEOUS LIQUID .. YES
DIGITAL CONTROL PANEL .......... FIN13 "V03"
ADJ TREATMENT TIME ............. (00:00-500:59 MMM:SS)
TEMPERATURE ................... YES (THREE PROGRAMMABLE PRESETS)
TEMPERATURE LIMIT .............. (7-DAY TIMER)
FINNSONIC CNC CONTROL SYSTEM:
FERROPLAN ROLLER CONVEYOR:
SERIAL ......................................... 12754-21-153090
YEAR ........................................... 2018
EXTERNAL CONTROL ............................... YES
TEMPERATURE INTERLOCK .......................... YES
DRY RUN PROTECTION ............................. YES
