SERIAL ......................... 012TL865
MODEL .......................... ALPHA T14IB
YEAR ........................... 2001
TRAVEL:
X AXIS TRAVEL .................. 20"
Y AXIS TRAVEL .................. 15.75"
Z AXIS TRAVEL .................. 13.00"
SPINDLE:
SPEED RANGE ................... 15,000 RPM
TAPER ......................... BT 30
NOSE TO TABLE TOP ............. 5.9" - 18.89"
MOTOR ......................... 7.5HP/5HP AC
TABLE LOAD CAPACITY ........... 242 LBS
RAPID TRAVERSE RATES .......... 2125 IPM
MAX TAPPING SPEED ............. 5000 RPM
TOOL CHANGE TIME .............. 0.9/1.4 SEX
PALLET CHANGE TIME ............ 6.2 SECS
EQUIPPED WITH:
FANUC 16IMA CONTROL
PALLET CHANGER
| Specifications | ||
|---|---|---|
| Weight | 12500 pounds | |
Brand
Fanuc Robodrill
Type
Drilling & Tapping Machines
Stock No.
14515
 |
419-269-2000 |
Stock #: 14515
SERIAL ......................... 012TL865
MODEL .......................... ALPHA T14IB
YEAR ........................... 2001
TRAVEL:
X AXIS TRAVEL .................. 20"
Y AXIS TRAVEL .................. 15.75"
Z AXIS TRAVEL .................. 13.00"
SPINDLE:
SPEED RANGE ................... 15,000 RPM
TAPER ......................... BT 30
NOSE TO TABLE TOP ............. 5.9" - 18.89"
MOTOR ......................... 7.5HP/5HP AC
TABLE LOAD CAPACITY ........... 242 LBS
RAPID TRAVERSE RATES .......... 2125 IPM
MAX TAPPING SPEED ............. 5000 RPM
TOOL CHANGE TIME .............. 0.9/1.4 SEX
PALLET CHANGE TIME ............ 6.2 SECS
EQUIPPED WITH:
FANUC 16IMA CONTROL
PALLET CHANGER
