| Specifications | ||
|---|---|---|
| Dimensions | 51" X 31" X 88" | |
Brand
CLEEREMAN
Type
Boring Mills, Vertical
Stock No.
18371
 |
419-269-2000 |
Stock #: 18371
MODEL ..................................... BOX COLUMNSPINDLE CENTER TO LOWER COLUMN ............ 12-1/2"SPINDLE CENTER TO UPPER COLUMN ............ 11-1/2"AREA OF WORK TABLE ........................ 19" X 24"VERTICAL TABLE TRAVEL ..................... 12"MAXIMUM DISTANCE SPINDLE NOSE TO TABLE .... 27"VERTICAL ADJUSTMENT OF SLIDING HEAD ....... 18"POWER FEED SPINDLE TRAVEL ................. 12"SPINDLE SPEEDS ............................ (12) 75 TO 1500 RPMSPINDLE FEEDS ............................. (9) .005 TO .045 IPRSPINDLE TAPER ............................. #4 MTPOWER DOWNFEED ............................ YESMOTOR ..................................... 5 HORSEPOWER
