SERIAL ........................ 10735
MODEL ......................... 8 HYDRAULIC
NEW ........................... 1988
CAPACITY ...................... 4'
CAPACITY, THICKNESS ........... .859" BOILER DUTY, .641" PIPE DUTY
TOP ROLL DIAMETER ............. 7"
TOP ROLL LENGTH ............... 56"
BOTTOM & SIDE ROLL DIAMETER ... 10"
BOTTOM & SIDE ROLL LENGTH ..... 50"
BETWEEN FRAMES ................ 52"
PLATE FEEDING SPEED ........... 20 FPM
SPEED CONTROL ................. VARIABLE VIA JOY STICK
LOWER PINCH ROLL ACTION ....... HYDRAULIC
SIDE ROLLS ACTIN .............. HYDRAULIC
DROP END ACTION ............... HYDRAULIC
POSITIONING ........................ DIGITAL READ OUT
BERTSCH CONTROLLER ............ YES
MOTOR ......................... 15 HP
Brand
BERTSCH
Type
Rolls, Plate Bending (incld Pinch)
Stock No.
14330
 |
419-269-2000 |
Stock #: 14330
SERIAL ........................ 10735
MODEL ......................... 8 HYDRAULIC
NEW ........................... 1988
CAPACITY ...................... 4'
CAPACITY, THICKNESS ........... .859" BOILER DUTY, .641" PIPE DUTY
TOP ROLL DIAMETER ............. 7"
TOP ROLL LENGTH ............... 56"
BOTTOM & SIDE ROLL DIAMETER ... 10"
BOTTOM & SIDE ROLL LENGTH ..... 50"
BETWEEN FRAMES ................ 52"
PLATE FEEDING SPEED ........... 20 FPM
SPEED CONTROL ................. VARIABLE VIA JOY STICK
LOWER PINCH ROLL ACTION ....... HYDRAULIC
SIDE ROLLS ACTIN .............. HYDRAULIC
DROP END ACTION ............... HYDRAULIC
POSITIONING ........................ DIGITAL READ OUT
BERTSCH CONTROLLER ............ YES
MOTOR ......................... 15 HP
