Brand
IKEDA
Type
Drills, Radial
Stock No.
17077
 |
419-269-2000 |
Stock #: 17077
SERIAL ............................ 6572MODEL ............................. RM-1300NEW ............................... 1965ARM LENGTH X COLUMN DIAMETER ...... 4' X 13-5/8"AREA OF BASE (T-SLOTTED) .......... 52" X 36"SPINDLE SPEEDS .................... (12) 30 TO 1440 RPMSPINDLE FEEDS ..................... .004-.008-.013-.021 IPRSPINDLE DIAMETER .................. 3-3/8"SPINDLE STROKE .................... 10"SPINDLE TAPER ..................... #5 MTSPINDLE TO COLUMN ................. 10" MIN. / 48" MAX.SPINDLE TO BASE ................... 15" MIN. / 49" MAX.BASE HEIGHT ....................... 8-1/2"COLUMN CLAMPING ................... POWERARM ELEVATION ..................... POWERHEAD TRAVERSE ..................... POWERCOOLANT ........................... YESSPINDLE MOTOR ..................... 5 HORSEPOWER
