WORK TABLE DIAMETER ............... 36"
MAXIMUM SWING INSIDE GUARDS ....... 44"
NOMINAL HOLE ABILITY .............. 18"
MAX HEAD STROKE ................... 36"
DISTANCE UNDER RAIL ............... 25-1/2"
HEAD ANGLE SETTING ................ 45 DEG
CHUCK SPEED RANGE ................. 6-120 RPM
HEAD STROKE,FEED RATE ............. 0-80 IPM
CROSS FEED RATE,RANGE(IPD) ........ .0002 - .003
TARRY PERIOD ...................... 0 - 14 SECONDS
GRINDING WHEEL HP ................. 10
MAX SPINDLE SPEED ................. 4,000 RPM
Brand
SPRINGFIELD
Type
Grinders, Vertical Universal
Stock No.
22407
 |
419-269-2000 |
Stock #: 22407
WORK TABLE DIAMETER ............... 36"
MAXIMUM SWING INSIDE GUARDS ....... 44"
NOMINAL HOLE ABILITY .............. 18"
MAX HEAD STROKE ................... 36"
DISTANCE UNDER RAIL ............... 25-1/2"
HEAD ANGLE SETTING ................ 45 DEG
CHUCK SPEED RANGE ................. 6-120 RPM
HEAD STROKE,FEED RATE ............. 0-80 IPM
CROSS FEED RATE,RANGE(IPD) ........ .0002 - .003
TARRY PERIOD ...................... 0 - 14 SECONDS
GRINDING WHEEL HP ................. 10
MAX SPINDLE SPEED ................. 4,000 RPM
