| Specifications | ||
|---|---|---|
| Dimensions | 120" F-B, 60" L-R, 140" HIGH | |
| Weight | 25500 pounds | |
Brand
PACIFIC
Type
Presses, C-Frame
Stock No.
14069
 |
419-269-2000 |
Stock #: 14069
SERIAL ...................... 5850NEW ......................... 1973MODEL ....................... 300 PF PRESSFORMERCAPACITY .................... 300 TONSTROKE (FACTORY EXTENEDED) .. 24"
OPEN HEIGHT ................. 36"
CLOSED HEIGHT ............... 12"
ADVANCE SPEED ............... 78" IPM
PRESSING SPEED .............. 36" IPMRETURN SPEED ................ 72" IPMTABLE AREA .................. 24" X 60"
TABLE T SLOTS ............... 2 @ 60" LONG X 8" CENTERS
RAM AREA .................... 18" X 18"
RAM T SLOTS ................. 2 @ 18" LONG X 8" CENTERS
ALL T SLOTS ................. 3/4" TOP WIDTH X 1.5" BOTTOM WIDTH X 1.125" DEEPPASS HEIGHT ................. 32"THROAT ...................... 14"DISTANCE BETWEEN HOUSINGS ... 20" INSIDE
FRAME HOUSING THICKNESS ..... 3" PER SIDEFLUSH FLOOR DESIGN .......... YESVOLTAGE ..................... 230/460V, 3 PH
MOTOR ....................... 40 HP
