SERIAL .................... 178366
MODEL ..................... 931186
CAPACITY .................. 300 TON
STROKE OF RAM ............. 16"
BETWEEN STRAIN BARS ....... 60"
RAM CENTER TO FLOOR ....... 36"
RAM TO RESISTANCE BLOCK ... 16" TO 72"
WIDTH OF RESTANCE BLOCK ... 28"
HOLE IN RESISTANCE BLOCK .. 14"
PUSH ADAPTOR PLATES ....... 8", 10", 12" DIAMETER
PRESSURE TONNAGE GUAGE .... YES
HYDRAULIC UNIT MOTOR ...... 7.5 HP
| Specifications | ||
|---|---|---|
| Weight | 12600 pounds | |
Brand
DAKE
Type
Presses, Wheel
Stock No.
16473
 |
419-269-2000 |
Stock #: 16473
SERIAL .................... 178366
MODEL ..................... 931186
CAPACITY .................. 300 TON
STROKE OF RAM ............. 16"
BETWEEN STRAIN BARS ....... 60"
RAM CENTER TO FLOOR ....... 36"
RAM TO RESISTANCE BLOCK ... 16" TO 72"
WIDTH OF RESTANCE BLOCK ... 28"
HOLE IN RESISTANCE BLOCK .. 14"
PUSH ADAPTOR PLATES ....... 8", 10", 12" DIAMETER
PRESSURE TONNAGE GUAGE .... YES
HYDRAULIC UNIT MOTOR ...... 7.5 HP
