SERIAL ..................... 47993
MODEL ...................... 2516
SWING OVER WAYS ............ 28"
SWING OVER CROSS SLIDE ..... 21"
CENTER DISTANCE ............ 192"
SPINDLE SPEEDS ............. 8 TO 450 RPM
FEEDS ...................... .005 TO .160 IPR
THREADS .................... 1 TO 64 TPI
SPINDLE HOLE ............... 8-9/16"
CHUCKS FRONT & REAR ........ 21" 3 & 4 JAW
TAPER ATTACHMENT .......... YES
RAPID TRAVERSE ............ 4 WAY
THREAD DIAL ............... YES
SWIVEL COMPOUND ........... YES
COOLANT WITH CHIP PANS .... YES
MOTOR ..................... 30 HORSEPOWER
Brand
LODGE & SHIPLEY
Type
Lathes, Engine
Stock No.
10878
 |
419-269-2000 |
Stock #: 10878
SERIAL ..................... 47993
MODEL ...................... 2516
SWING OVER WAYS ............ 28"
SWING OVER CROSS SLIDE ..... 21"
CENTER DISTANCE ............ 192"
SPINDLE SPEEDS ............. 8 TO 450 RPM
FEEDS ...................... .005 TO .160 IPR
THREADS .................... 1 TO 64 TPI
SPINDLE HOLE ............... 8-9/16"
CHUCKS FRONT & REAR ........ 21" 3 & 4 JAW
TAPER ATTACHMENT .......... YES
RAPID TRAVERSE ............ 4 WAY
THREAD DIAL ............... YES
SWIVEL COMPOUND ........... YES
COOLANT WITH CHIP PANS .... YES
MOTOR ..................... 30 HORSEPOWER
