SERIAL 0-24345
NEW 1978
MODEL SC2-250-84-42
CAPACITY 250 TON
STROKE 10"
ADJUSTMENT 11"
SHUT HEIGHT 33" SDAU
SPEED 30 TO 80 SPM
BED 84" X 42"
BETWEEN HOUSINGS 93.25"
WINDOWS 50" X 24" HIGH
BED TO FLOOR 34"
BOLSTER THICKNESS 6.5"
AIR CLUTCH & BRAKE
CONTROLS
CUSHIONS 2
CUSHION STROKE 5"
OVERALL DIMENSIONS 167" X 101.5" X 200" HIGH
FOOTPRINT 115" X 99"
Brand
NIAGARA
Type
Presses, Straight Side, Double Crank (Single Action)
Stock No.
24783
Files
 |
419-269-2000 |
Stock #: 24783
SERIAL 0-24345
NEW 1978
MODEL SC2-250-84-42
CAPACITY 250 TON
STROKE 10"
ADJUSTMENT 11"
SHUT HEIGHT 33" SDAU
SPEED 30 TO 80 SPM
BED 84" X 42"
BETWEEN HOUSINGS 93.25"
WINDOWS 50" X 24" HIGH
BED TO FLOOR 34"
BOLSTER THICKNESS 6.5"
AIR CLUTCH & BRAKE
CONTROLS
CUSHIONS 2
CUSHION STROKE 5"
OVERALL DIMENSIONS 167" X 101.5" X 200" HIGH
FOOTPRINT 115" X 99"
