| Specifications | ||
|---|---|---|
| Chuck Size | 15 inches | |
| Swing in Gap | 21 inches | |
| Spindle Speed RPM | 1400 | |
| Main Motor | 12.5 | |
| Threads Per Inch | 72 | |
| Threads Per Millimeter | 14 | |
Brand
CLAUSING COLCHESTER
Type
Lathes, Engine
Stock No.
17305
 |
419-269-2000 |
Stock #: 17305
SERIAL ........................... 8/0226/03709
MODEL ............................ 21
SWING OVER BED ................... 21"
SWING OVER CROSS SLIDE ........... 14-1/2"
DISTANCE BETWEEN CENTERS ......... 108"
SPINDLE SPEEDS ................... (16) 18 TO 1400 RPM
ENGLISH FEEDS .................... (13) .002 TO .032 IPR
METRIC FEEDS ..................... (13) .06 TO 1 MMPR
ENGLISH THREADS .................. (38) 2 TO 72 TPI
METRIC THREADS ................... (40) .4 TO 14 TPMM
HOLE THRU SPINDLE ................ 3-1/2"
THREAD DIAL ...................... YES
TRAVEL DIAL ...................... YES
CHUCK ........................... 15" 3 JAW CHUCK
TAIL STOCK TAPER ................. #5 MT
COOLANT WITH CHIP PANS ........... YES
MOTOR ............................ 12.5 HORSEPOWER
