| Specifications | ||
|---|---|---|
| Weight | 12250 pounds | |
Brand
CINCINNATI
Type
Millers, Production, Simplex (Hor.)
Stock No.
14138
 |
419-269-2000 |
Stock #: 14138
MODEL ................................. #4-36 HYDROMATICAREA OF TABLE (T-SLOTTED) ............. 53" X 16"LONGITUDINAL TABLE TRAVEL ............. 36"VERTICAL TRAVEL OF HEAD .............. 11-1/4"DISTANCE SPINDLE TO TABLE ............. 5-3/4" MIN. TO 16" MAX.STANDARD SPINDLE SPEEDS ............... (8) 20 TO 150 RPMSPINDLE TRAVEL ........................ 6"TABLE FEEDS (VARIABLE) ................ 0 TO 40 IPMDISTANCE SPINDLE TO CENTER OF TABLE ... 12-9/16"DISTANCE CENTER OF SPINDLE TO OVERARM . 10-3/8"TAPER IN SPINDLE ...................... #50 NSMAIN MOTOR ............................ 15 HORSEPOWER
