YEAR NEW..................... 1999
CAPACITY..................... 15 TON / 30,000 LBS
SPAN......................... 44'7"
AVAILABLE LIFT .............. 36'
CLASS........................ C
CONSTRUCTION ................ 4 MOTOR
TOP RUNNING BRIDGE .......... DOUBLE GIRDER
HOIST........................ TOP RUNNING - LIFT TECH SERIES 700
BRIDGE SPEED................. 0 TO 120 FPM VARIABLE
BRIDGE MOTORS ............... 2 AT 2 HP EACH
HOIST SPEED.................. 0 TO 14 FPM VARIABLE
HOIST MOTOR ................. 15 HP
TROLLEY SPEED................ 0 TO 65 FPM VARIABLE
TROLLEY MOTOR ............... .75 HP
BRIDGE WHEEL BASE ........... 10'
END TRUCK LENGTH ............ 13'11"
HOIST GAUGE ................. 6'6"
TOTAL WEIGHT ................ 20,223 LBS
BEAM TO TOP OF HOIST ........ 5' (HEADROOM)
Brand
PROSERV
Type
Cranes, Bridge & Overhead
Stock No.
21738
 |
