Serial ................. 1P4L5C-0001
SPECIFICATIONS:
Swing Over Bed .......... 14.5”
Max. Roll Length ........ 192”
Max. Roll Weight......... 5,000 LBS
WORKHEAD:
Workhead Type Dead
Workhead Speeds ......... 0 TO 100 RPM Programmable
Workhead Center Taper ... #13 Brown and Sharp
WHEELHEAD:
Grinding Wheel Size ..... 30” x 3” x 12” STD
Wheel Speeds ............ 200 – 1000 RPM
Motor ................... 20 HP
TABLE:
Table Traverse Speed .... 2.0 – 118 IPM (VARIABLE)
Table Swivel ............ 5 degrees
Handwheel Feed .......... 0.1” – 0.6” (1 Revolution)
Rack and Pinion table drive
FOOTSTOCK:
Footstock Type .......... Handwheel
Footstock Center ........ #13 Brown And Sharp
EQUIPMENT SUPPLIED:
(1) Wheel Mount
Tailstock Mounted Wheel Dresser with Diamond
Coolant Splash Guards
RECENT WORK DOWN:
Tailstock, headstock, tables removed, lube system cleaned and flushed. New headstock and spindle belts, cleaned up electrics. Cleaned and painted. Checked for proper operation.
Tailstock disassembled, cleaned, assembled and checked for proper operation.
Headstock covers removed, inspected bearings and drive chains.
| Specifications | ||
|---|---|---|
| Dimensions | 42' x 96"' x 72" HIGH | |
| Weight | 38000 pounds | |
Brand
CINCINNATI GRINDERS INC
Type
Grinders, Cylindrical (Incl Plain & Angle Head)
Stock No.
14147
Files
 |
419-269-2000 |
Stock #: 14147
Serial ................. 1P4L5C-0001
SPECIFICATIONS:
Swing Over Bed .......... 14.5”
Max. Roll Length ........ 192”
Max. Roll Weight......... 5,000 LBSWORKHEAD:
Workhead Type Dead
Workhead Speeds ......... 0 TO 100 RPM Programmable
Workhead Center Taper ... #13 Brown and SharpWHEELHEAD:
Grinding Wheel Size ..... 30” x 3” x 12” STD
Wheel Speeds ............ 200 – 1000 RPM
Motor ................... 20 HPTABLE:
Table Traverse Speed .... 2.0 – 118 IPM (VARIABLE)
Table Swivel ............ 5 degrees
Handwheel Feed .......... 0.1” – 0.6” (1 Revolution)
Rack and Pinion table driveFOOTSTOCK:
Footstock Type .......... Handwheel
Footstock Center ........ #13 Brown And SharpEQUIPMENT SUPPLIED:
(1) Wheel Mount
Tailstock Mounted Wheel Dresser with Diamond
Coolant Splash Guards
RECENT WORK DOWN:Tailstock, headstock, tables removed, lube system cleaned and flushed. New headstock and spindle belts, cleaned up electrics. Cleaned and painted. Checked for proper operation.
Tailstock disassembled, cleaned, assembled and checked for proper operation.
Headstock covers removed, inspected bearings and drive chains.
