SERIAL ............................ 196688E00
MODEL ............................. 120-I/50-FS
YEAR NEW .......................... 2007
WELDING LENGTH ................... 120"
LENGTH OF CLAMP AREA .............. 126"
WORK MATERIAL THICKNESS RANGE ..... 0.020" TO .375"
WORK PIECE MINIMUM DIAMETER ....... 50"
PLATEN HEIGHT ..................... 22"
PLATEN END LATCH .................. YES
BACK UP BAR ....................... PLAIN COPPER STANDARD
CLAMPING FINGERS .................. 6" ALUMINUM ALLOY
CLAMPING PRESSURE ................. 0 TO 200# PER INCH
ALIGNMENT GAUGES .................. ENTIRE LENGTH, ADJUSTABLE
SEAMING HEAD TRAVEL ............... 0 TO 100 IPM
SEAMING HEAD DELAY TIMER .......... 0 TO .25
RAPID TRAVERSE ......... .......... YES
CARRIAGE CONTROLS ................. PANDJIRIS EZ LINK
PENDANT CONTROL ................... YES
LINCOLN WELDER .................... POWERWAVE AC/DC 1000SD
LINCOLN CARRIAGE TRAVEL CONTROL ... CS 250
LINCOLN CONTROLLER ................ MAXSA 10
WELD ENGINEERING FLUX RECOVERY .... MODEL XP-3
Brand
PANDJIRIS
Type
Welders, Seam
Stock No.
10059
 |
419-269-2000 |
Stock #: 10059
SERIAL ............................ 196688E00
MODEL ............................. 120-I/50-FS
YEAR NEW .......................... 2007
WELDING LENGTH ................... 120"
LENGTH OF CLAMP AREA .............. 126"
WORK MATERIAL THICKNESS RANGE ..... 0.020" TO .375"
WORK PIECE MINIMUM DIAMETER ....... 50"
PLATEN HEIGHT ..................... 22"
PLATEN END LATCH .................. YES
BACK UP BAR ....................... PLAIN COPPER STANDARD
CLAMPING FINGERS .................. 6" ALUMINUM ALLOY
CLAMPING PRESSURE ................. 0 TO 200# PER INCH
ALIGNMENT GAUGES .................. ENTIRE LENGTH, ADJUSTABLE
SEAMING HEAD TRAVEL ............... 0 TO 100 IPM
SEAMING HEAD DELAY TIMER .......... 0 TO .25
RAPID TRAVERSE ......... .......... YES
CARRIAGE CONTROLS ................. PANDJIRIS EZ LINK
PENDANT CONTROL ................... YES
LINCOLN WELDER .................... POWERWAVE AC/DC 1000SD
LINCOLN CARRIAGE TRAVEL CONTROL ... CS 250
LINCOLN CONTROLLER ................ MAXSA 10
WELD ENGINEERING FLUX RECOVERY .... MODEL XP-3
