SERIAL ............................ 6857
| Specifications | ||
|---|---|---|
| Weight | 4925 pounds | |
| COOLANT WEIGHT | 225 pounds | |
Brand
OKAMOTO
Type
Grinders, Surface, Recip.
Stock No.
14657
 |
419-269-2000 |
Stock #: 14657
SERIAL ............................ 6857
NEW ............................... 1992
MODEL ............................. 124N ACCUGARCAPACITY .......................... 12" X 24"MAXIMUM UNDER WHEEL ............... 13.7"HYDRAULIC TABLE FEED .............. 1 TO 100 FPMLONGITUDINAL TABLE TRAVEL ......... 26"AUTO CROSS TRAVEL ................. 13.6"LONGITUDINAL FEEDS INTERMITTENT ... 0.02" TO 0.8"LONGITUDINAL FEEDS CONTINUOUS ..... 4 TO 40 IPMCROSS FEED RATE INTERMITTENT ...... 0.02" TO 0.8"CROSS FEEDS RATE CONTINUOUS ....... 4 TO 40 IPMINCREMENTAL DOWN FEED OF HEAD ..... YESAUTO FEED PER TABLE STROKE ........ 0.0015" TO .0001"AUTO FEED PER SADDLE REVERSE ...... 0.0015" TO .0001"RAPID FEED RATE ................... 19 IPMGRINDING WHEEL SIZE ............... 12" X 1-1/2" X 5"OVER THE WHEEL DRESSER ............ YESCHUCK VARIABLE HOLD ............... 12" X 24" X 3"SPINDLE MOTOR ..................... 5 HORSEPOWERHYDRAULIC MOTOR ................... 2 HORSEPOWER
