SERIAL ........................ 3SB29061
Brand
SUMMIT
Type
Lathes, Gap Bed
Stock No.
12269
 |
419-269-2000 |
Stock #: 12269
SERIAL ........................ 3SB29061
MODEL ......................... SNB400X2000SWING OVER WAYS ............... 17"SWING IN GAP .................. 27"SWING OVER CROSS SLIDE ........ 8.5"DISTANCE BETWEEN CENTERS ...... 84"SPINDLE SPEEDS ................ (12) 25 TO 2000 RPMENGLISH TREADS ................ 4 TO 92 TPIMETRIC THREADING .............. 0.5 TO 11.5 MMFEEDS ......................... (63) .0018 TO .0752 MMPRDIAMETER OF SPINDLE HOLE ...... 2"CHUCK ......................... 12.5" 4 JAWTAPER ATTACHMENT .............. YESTHREAD DIAL ................... YES
TAIL STOCK .................... #3 MT
STEADY RESTS .................. (2) 8" EACHCOOLANT & CHIP PANS ........... YESMOTOR ......................... 10 HORSEPOWER
