SERIAL .................. 3352
MODEL ................... 100VC
CAPACITY ................ 100 TON
TYPE .................... C-FRAME
T-SLOTTED BED SIZE ...... 16" X 48"
T-SLOTTED RAM FACE ...... 12" X 20"
BETWEEN HOUSINGS ........ 18"
STROKE .................. 12"
OPEN HEIGHT ............. 22"
CLOSED HEIGHT ........... 10"
THROAT .................. 21"
ADVANCE SPEED ........... 75 IPM
PRESS SPEED ............. 33 IPM
RETURN SPEED ............ 71 IPM
CONTROLS ................ FOOT SWITCH
TOP MOUNTED HYDRAULICS .. YES
MAIN MOTOR .............. 12.5 HP
| Specifications | ||
|---|---|---|
| Dimensions | 73 X 48 X 106" HIGH. | |
| Weight | 9550 pounds | |
Brand
PACIFIC
Type
Presses, Hydraulic
Stock No.
16251
 |
419-269-2000 |
Stock #: 16251
SERIAL .................. 3352
MODEL ................... 100VC
CAPACITY ................ 100 TON
TYPE .................... C-FRAME
T-SLOTTED BED SIZE ...... 16" X 48"
T-SLOTTED RAM FACE ...... 12" X 20"
BETWEEN HOUSINGS ........ 18"
STROKE .................. 12"
OPEN HEIGHT ............. 22"
CLOSED HEIGHT ........... 10"
THROAT .................. 21"
ADVANCE SPEED ........... 75 IPM
PRESS SPEED ............. 33 IPM
RETURN SPEED ............ 71 IPM
CONTROLS ................ FOOT SWITCH
TOP MOUNTED HYDRAULICS .. YES
MAIN MOTOR .............. 12.5 HP
